Imer USA  |  SKU: 1194644

Mix 750 - Vertical Shaft Mixer

$13,499.00
Shipping calculated at checkout.

Produce 16 cubic feet of Mud Every Three to Four Minutes with the Mix 750

The Mix 750 is the perfect partner for busy precast mixing operations. The discharge system is easy to open and close and protected from being hit by a mud bucket or forklift. The safety grate is hinged, making access immediate. The Mix 750 is Mini-Batch Plant production for the cost of a mortar mixer. These mixers develop vast amounts of mixing power, far more than any horizontal shaft mortar mixer. The ability to mix refractory mud or stiff, dry materials is unparalleled in the industry.

Please note these mixers are made to order - please expect extended delivery times.



Standard Features

• Honda gasoline, single or 3 phase electric motor options
• Tow package - bar, hitch
• 22" pneumatic highway tires and torsion bar suspension
• 22 cu ft drum capacity
• 16 cu ft batch output
• ​Forklift pockets



Technical Specs



IMER Vertical Shaft Mixers Catalog

Mix 750 Imer USA
Imer USA

Mix 750 - Vertical Shaft Mixer

From $13,499.00
Produce 16 cubic feet of Mud Every Three to Four Minutes with the Mix 750

The Mix 750 is the perfect partner for busy precast mixing operations. The discharge system is easy to open and close and protected from being hit by a mud bucket or forklift. The safety grate is hinged, making access immediate. The Mix 750 is Mini-Batch Plant production for the cost of a mortar mixer. These mixers develop vast amounts of mixing power, far more than any horizontal shaft mortar mixer. The ability to mix refractory mud or stiff, dry materials is unparalleled in the industry.

Please note these mixers are made to order - please expect extended delivery times.



Standard Features

• Honda gasoline, single or 3 phase electric motor options
• Tow package - bar, hitch
• 22" pneumatic highway tires and torsion bar suspension
• 22 cu ft drum capacity
• 16 cu ft batch output
• ​Forklift pockets



Technical Specs



IMER Vertical Shaft Mixers Catalog

Engine Type

  • 5 HP - 208V/60Hz - Single Phase
  • 7.5 HP - 208V / 60Hz - 3 Phase
  • 7.5 HP - 480V / 60Hz - 3 Phase
  • 7.5 HP 600V / 60Hz - 3 Phase
  • 13 HP - Honda GX with Electric Start
